A FAMILY

dancoo A

Packaging and transportatinon

Net weight (kg)

225

Gross weight (kg)

303

UNIT/20GP

UNIT/40GP

UNIT/40HQ

Packaging size

2270 × 1100 × 550mm

Feature

Exterior

PET Cover

Glass (door & rear)

Tempered glass

Frame and table

Laminate on plywood

Weight

225.4

Measurements

Exterior (height, width, depth)

220 × 100 × 100cm

Interior (height, width, depth)

200 × 84.8 × 96cm

Door (height, width)

202.8 × 87.2cm

Table (width, depth, height)

84.4 × 30 × 12cm

Height from the floor to table: 105cm

Power consumption

Power consumption standard

3.24W while in use

LED light :1.8W

Fans in total: 1.44W

0.75W standby power consumption or up on request Power consumption option LED light: LED brightness adjustment options

Fans in total: up to14.4W

Input: 110-240VAC, 10A, 50/60Hz

Outlets

Regular table:

Power socket + optional LAN cable (extra cost)

Output values

Output VAC (power socket):

100–240 VAC, 8 A, 50–60 Hz

Output USB charging:

USB Type A socket, Type C option, Maximum combined output 18 W

Air Ventilation

Air Ventilation Ventilation rate:

More than 1m³/ minute standard

Adjustable higher ventilation options

Acoustic performance

For speech level reduction (D_S,A) and Noise isolation class (NIC), third party test reports are available per request

Certificates

dancoo 2A

Packaging and transportatinon

Net weight (kg)

440

Gross weight (kg)

520

UNIT/20GP

UNIT/40GP

UNIT/40HQ

Packaging size

2270 × 650 × 1330mm

+900 × 900 × 1100mm

Feature

Exterior

PET Cover

Glass (door & rear)

Tempered glass

Frame and table

Laminate on plywood

Weight

440

Measurements

Exterior (height, width, depth)

220 × 220 × 120cm

Interior (height, width, depth)

204 × 206 × 111cm

Door (height, width)

202.8 × 87.2cm

Table (width, depth, height)

70 × 53 × 64cm

Power consumption

Power consumption standard

6.48W while in use

LED light :3.6W

Fans in total: 2.88W

0.75W standby power consumption or up on request Power consumption option LED light: LED brightness adjustment options

Fans in total: up to 28.8W

Input: 110-240VAC, 10A, 50/60Hz

Outlets

Regular sofa:

Power socket + optional LAN cable (extra cost)

Output values

Output VAC (power socket):

100–240 VAC, 8 A, 50–60 Hz

Output USB charging:

USB Type A socket, Type C option, Maximum combined output 18 W

Air Ventilation

Air Ventilation Ventilation rate:

More than 2m³/ minute standard

Adjustable higher ventilation options

Acoustic performance

For speech level reduction (D_S,A) and Noise isolation class (NIC), third party test reports are available per request
